Lynx 44
Roll over to zoom in

Lynx 44 (17” Bowl)

Engineered for construction mobility, this field-ready unit excels in dewatering and environmental remediation with rapid deployment capabilities and adaptable performance across variable feed conditions.

  • Prevents environmental contamination by efficiently separating soil, slurry, and construction byproducts
  • Enables quick redeployment between construction sites with minimal setup requirements
  • Ensures compliance with local discharge regulations during trenchless and conventional construction
  • Maintains consistent performance across variable environmental and feed conditions
See more details

Talk to Sales

CALL
EMAIL

Aux Equipment

Stands

Pumps

All Aux Equipment

Technical Specifications

Our expert team understands the ins and outs of fluid and solid separation processes, allowing us to bring together the right centrifuge configuration for any application. Review the Lynx 44 Technical Specifications below to see if it’s the right fit for your needs.



Typical solids capacity 8 t/h
Bowl diameter 440 mm / 17.3 inches
Bowl length 1760 mm / 69.3 inches
Bowl speed (maximum) 3800 rpm
G-force (maximum) 3558 G
Gross weight 3600 kg / 7937 lbs.
Length (L) 4708 mm / 185.4 inches
Width (W) 1060 mm / 41.7 inches
Height (H) 1382 mm / 54.4 inches
Back drive control* VFD
Main drive motor 50 hp or 60 hp
Back drive motor 30 hp
Hydraulic capacity 100 m³/h / 440 GPM
Centrifuge, VFD and Pump Power Requirements 100 amps 480v
