Our expert team understands the ins and outs of fluid and solid separation processes, allowing us to bring together the right centrifuge configuration for any application. Review the Lynx 20 Technical Specifications below to see if it’s the right fit for your needs.
| Typical solids capacity | 0.5 t/h |
|---|---|
| Bowl diameter | 200 mm / 7.9 inches |
| Bowl speed (maximum) | 5300 rpm |
| G-force (maximum) | 3146 G |
| Gross weight | 600 kg / 1323 lbs. |
| Length (L) | 2154 mm / 84.8 inches |
| Width (W) | 570 mm / 22.4 inches |
| Height (H) | 762 mm / 30.0 inches |
| Back drive control* | CS and VFD |
